| Sr. No |
Name of the Laboratory |
No. of Students per setup (Batch size) |
Name of the important equipment |
| 1 |
Advanced Communication Laboratory |
4 |
Optical Network Analysis System consisting of OTDR, OSA, Spicing Machine |
| Arbitrary Waveform Generator |
| Satellite Communication Trainer Kits |
| Fiber Optic Communication Trainer Kits |
| Light Runner Trainer Kits |
| 2 |
Industrial Robotics Lab |
12-18 |
KUKA KR16 Industrial Robot Manipulator |
| 3 |
Robotics Lab |
20 |
E-yantra Robotics lab setup, NI USRP, MATLAB 2014, 10 PC’s |
| 4 |
Microwave and RF Engineering Lab |
20 |
R&S Vector Network Analyser, |
| Vector Signal generator and Analyser, |
| R&S EMI/EMC Measurement system. |
| IE3D and FEKO Software |
| 5 |
Electronic Devices and Circuits Lab |
20 per batch |
Function Generator |
| power Supply |
| Analog Oscilloscopes |
| 6 |
VLSI Lab |
20 per batch |
Xilinx FPGA Virtex 5 |
| XILINX FPGA vertex 4 |
| XILINX FPGA SPARTAN 3 |
| ALTERA DE2 |
| ZEDBOARD ZYNQ SOC |
| XILINX FPGA vertex II Pro |
| HCL PCs |
| 7 |
Signal Processing Lab |
20 per batch |
DSO 100MHZ 2Ch, |
| DSO 100MHZ 4Ch, |
| Multiple power supply 0-30V 1A Scientech ST4074 |
| Desktop Machines (8) |
| 8 |
Basic Electronics Lab |
20 per batch |
Function Generator |
| DC power Supply |
| Analog Oscilloscopes |
| LCR Q Meter |
| 9 |
Industrial Automation Lab |
20 |
NI LabVIEW |
| Allen Bradley PLC |
| Scientech PLC,Delta PLC |
| Pneumetic Trainer |
| Hydraulic Trainer |
| Transducer trainer kits |
| 10 |
Communication Engineering Lab |
20 |
1 GHZ Spectrum Analyzer |
| “Scientific” Digital Storage Oscilloscope |
| "Techtronix” Digital Storage Oscilloscope |
| Satellite Communication Trainer ST 2271 |
| FM Communication Trainer ST 2204 |
| DSB/SSB AM Transmitter Trainer ST 2201 |
| DSB/SSB AM Receiver Trainer ST 2202 |
| 11 |
Integrated Electronics Lab |
20 |
Fluke 345 power quality analyzer |
| Fluke 190-102 100MHZ oscilloscope (handheld) with inbuilt multimeter |
| Fluke 124/0085 handheld 40MHZ battery operated oscilloscope cum multimeter |
| Power analyser |
| Techlab with powerscope and powersupply |
| 30MHZ dual channel dual trace powerscope scientech caddo 824 |
| APLAB 25MHZ 500msps color digital power oscilloscope |
| SCR, Triac, diac, mosfet, igbt characteristic study kit |
| Dc chopper power circuit Pragma DLP |
| DC chopper firing circuit Pragma DCT |
| EDKITS - Study of open loop control system |
| EDKITS - Study of closed loop control system |
| Basic feedback control trainer |
| lead lag network trainer |
| test signal generator for type 1,2,0 systems closed loop control system |
| type 0 control system kit |
| type 1 control system kit |
| type 2 control system kit |
| Digital control system (ADTRON) |
| PID control system (ADTRON) |
| Forced Commutation study unit Pragma FCU |
| single phase fully commutation converter Pragma SFC |
| 12 |
Biomedical Instrumentation and Consumer Electronics Lab |
20 |
Heart Lung Machine |
| ECG Measurement trainer, Simulator |
| EEG trainer, Simulator |
| EMG Trainer, Simulator |
| Surgical diathermy Trainer and Analyzer |
| X-Ray Machine Trainer and Model |
| Defrabrillator Trainer and Simulator |
| Digital Blood pressure machine |
| Holter Machine |
| Sugar Level detector measurement trainer kit |
| Stethoscope |
| Digital Spectrometer |
| Photo electric calorimeter |
| Human Anatomy torso |
| Defibrillator trainer demonstrator Unit |
| Siemens make(AC/DC) Programable Logic Controller |
| Programable Logic Controller,Transistor output (Delta Make) |
| Scada software(Delta Make) |
| Servo Drive and Servo Motor |
| Human Machine Interface (Delta Make) |
| Data Logger. |
| RS 485,RS 232 Interface. |
| Microwave Oven Trainer |
| Washing Machine Trainer |
| PA System |
| Sound Trainer Kits |
| 13 |
Computer Network and IOT Lab |
20 |
Cisco Router(3 Interfaces) |
| Cisco Switch (Managed 24 Port) |
| Cisco Layer 3 Switch ( Managed 24 Port) |
| Dlink Router |
| Dlink Switch |
| Cisco Firewall |
| Multimedia LCD Projector |
| Netsim Software |
| LX Infinity pro Bl Computers |
| ACE 16 port unmanaged switch |
| 10 KVA high power UPS with 10 kva UPS uniline |
| LC Projector(NEC NP400) |
| Flat bed scnner A4 HP |
| Dlink 3 ISDN Trainer System |
| 14 |
Microprocessor and Embedded Systems Lab |
20 |
8085/8086 Micro-controller Trainer kits |
| PC based logic analyser |
| PIC 16 Micro-controller Trainer kits |
| Digital IC Tester |
| 8051 Trainer kit |
| 32 channel stand alone logic analyser |
| 16/32 bit ARM based trainer cum development board |
| ARM7 TDMI LPC 2148 kits |
| Raspberry Pi kits |
| Galileo Boards |
| PIC 18F45XX Development board |
| 15 |
Computer Center |
20 |
FPGA Boards from Xilinx: Zedboard, Microzed ; FPGA Boards from Altera:Cyclone V |
| SDR board: AD9361 from Analog Devices |
| GPGPU boards from NVIDIA: Tesla,Titan, Jetson TK1,GeForce |
| ARM Discovery boards |
| 40 PCs with Linux OS, MATLAB 2014, CUDA software, server machine |
